Single Board Server X86 Hardware Router | Personal Cloud | 4K Media Server – SATA 6.0 Gb/s for HDD/SSD PCIe x4 – UHD Output – Pre-Installed CasaOS (ZimaBoard 232 2G/32G)

Price: $139.90 - $75.90
(as of Oct 09, 2024 23:23:45 UTC – Details)

Product Description

The video showcases the product in use.The video guides you through product setup.The video compares multiple products.The video shows the product being unpacked.

World’s First Hackable x86 Single Board Server

File share &Collaboration

Share disk at home or office. Collaborate on docs, videos, photos across systems in real-time.

Personal Cloud

Expand ZimaBoard to 36TB (2 x SATA) as your data grows. Enjoy local-disk speed via gigabit network.

Plex Media Server

Transform media with ZimaBoard & Plex. Stream movies, shows & tracks, redefining media experience.

CasaOS – Your Personal Cloud

ZimaBoard with CasaOS: user-friendly home OS. Manage your server with Docker apps and drive tools.

Software Router

Use ZimaBoard’s x86 chipset as a hardware router. Set up secure VPN, FTP, BitTorrent easily.

1 File share &Collaboration

2 Personal Cloud

3 Plex Media Server

4 CasaOS

5 Software Router

ZimaBoard: Cluster Innovation in Your Hands! ZimaCluster

Clustering is a revolutionary approach that allows you to combine the power of our servers with Proxmox to create high-performance clusters. By leveraging this technology, you can achieve enhanced reliability, increased performance, and seamless scalability for your critical workloads.

Fully Expandable

Easily upgrade with 2.5Gbe, NVMe NGFF SSD, WiFi dongle, XMOS/DAC module, and more!

Personal Server

ZimaBoard Ideal for git, web (Apache/lighttpd/NGINX), print, chat, or Minecraft servers.

OpenWRT

Run OpenWRT and pfSense on ZimaBoard,setup your VPN,hide your digital footprint, ban the ads.

Embedded Projects

ZimaBoard is the first private server designed for Makers, DIYers, and Hackers.

Firewall

Secure your network with ZimaBoard’s robust firewall capabilities.

1 Fully Expandable 2 Personal Server 3 OpenWRT 4 Embedded Projects 5 Firewall

Key Specification for ZimaBoard

Model ZimaBoard Processor Celeron Processor [Apollo Lake] N3350/N3450 Graphics HD Graphics 500 Memory LPDDR4 2GB/4GB/8GB Onboard Storage eMMC 5.1 32GB TDP 6W HDD / SSD 2x SATA 6.0 Gb/s Ports LAN 2x GbE LAN Ports USB 2x USB 3.0 PCIe 1x PCIe 2.0 x4 Display 1x Mini-DisplayPort 1.2 4K@60Hz Power DC 12V 5.5×2.5mm Cooling Passive Virtualization Intel VT-d, VT-x Pre-installed OS CasaOS Compatible OS Linux / Windows / OpenWrt / pfSense / Android / LibreELEC

What’s ZimaBoard for?

ZimaBoard makes home server setup easy with our custom OS. Quickly create Plex or Samba servers, add NVMe SSDs or up to 20TB via SATA. Expand with WIFI, USB, and extra Ethernet ports.

What features does it have?

ZimaBoard is perfect for DIYers and developers, featuring a quad-core x86 processor and PCIe for easy expansion. It comes with CasaOS, a user-friendly open-source private cloud system for home servers and projects.

What is the difference between ZimaBoard and Raspberry Pi?

ZimaBoard differs from Raspberry Pi with its x86/64 processor for better OS compatibility and performance, PCI slots for extensive expansion, SATA ports for direct storage connections, and dual Gigabit networking for built-in router/VPN functions.

Does ZimaBoard support Wake on LAN?

ZimaBoard features Wake on LAN (WoL), enabling remote power-on and wake-up from sleep or off states for convenient network access. This feature can be enabled or disabled through BIOS settings.

How to ssh ZimaBoard’s default OS?

To SSH into CasaOS:

1.Get IP: Check your router to find the CasaOS device IP. 2. SSH Command: Type casaos@IP_ADDRESS in your terminal. 3. Credentials: Use “casaos” for both username and password. 4. Quick and secure, you’re now connected to CasaOS.

World’s First Hackable x86 Single Board Server – ZimaBoard is a low-cost single board server exclusively designed for makers, DIYers and geeks. Equipped with Intel Celeron N3450 Quad Core operating at 1.1GHz to 2.2GHz, it has both the expandability of an x86 single-board computer, and the appropriate power of a micro server, perfect for edge intelligence and smart home projects.
PCIe x4, SATA 6.0 Gb/s & Dual Gigabit Ethernet Onboard – Fully customizable and expandable with onboard interfaces, PCIe x4 interface caters to a variety of user needs. Also, with a large number of PCIe accessories available in the market, you can easily extend your ZimaBoard setup with 2.5Gbe, NVMe NGFF SSD, WIFI dongle, XMOS/DAC module, and many more!
Personal NAS, 4K Streaming Server, VPN Router & IoT Gateway – With ZimaBoard, you can setup a 4 Terabyte personal cloud in 5 minutes and no more monthly bills, configure a secure VPN to protect your digital footprint, tune your network with OpenWrt and , build a 4K media server that runs with Plex, share and collaborate with team members on your files, or upgrade your smart projects across different systems.
Pre-installed CasaOS – A simple & elegant home cloud around Docker ecosystem, changing the way families view modern living. From photo and video storage to smart home device management, and encrypted communications, CasaOS is the one-stop ideal home cloud system to keep families safe and protected in the digital age. And zimaboard also compatible with OS like Linux(default)/ Windows / OpenWrt / Android / Libreelec.
Package Includes:1x ZimaBoard 232, 1x SATA Cable, 1x 12V/3A Power Adapter; Any questions, please email us by click the “zimaboard” or contact us with zimaboard offical site，We are always ready to ​listen to you.
